Hayward Slide Valves Manual Lawn

Step 1 FILTER OPERATION - For the majority of the time your Filter will operate in Filter mode. Water will enter from the pump into the top of the filter, flow through the sand to remove dirt particle and return to the pool from the bottom of the filter. Over time, the sand in the filter will become clogged with these dirt particles and will have to be cleaned. In Backwash Mode, the water is reversed through the filter.

FILTER - For normal filtering and regular vacuuming. BACKWASH - For cleaning filter sand bed of accumulated debris. RINSE - Use after completing. Use with Hayward Micro-Clear™ High Rate DE Filters. It is fitted with locking nuts. DE SLIDE VALVE MANUAL CMP 25831-004-000 (Replacement for Hayward SP0410X502S*).

Water from the pump is fed into the bottom of the filter tank, pushed up through the sand to release the trapped dirt particles and purged out a waste line connected to a port at the top of the Filter Tank. The Hayward Slide Valve is used to reverse the flow of water inside the Filter Tank. Step 3 WATER FLOW, FILTERING - When the Slide Valve is in the FILTER position, water flows from the PUMP into the middle Valve position and up into the upper piping of the Filter Tank. Healthstream Voyager Hs9000 Manual High School here. The top diffuser spreads the water evenly across the top of the sand, Then the water is filtered through the sand as it moves to the bottom of the Filter Tank. Here the water is collected into the bottom laterals; pushed up through the lower piping to exit out the lower Valve Port; and returned to the pool. The upper Valve port to the WASTE line is closed off.

Step 5 WATER FLOW, BACKWASHING - With the Slide Valve in the Backwash position, water flows from the PUMP through the middle port and down into the lower piping of the Filter Tank. The water is then dispersed into the bottom of the tank through the laterals, then forced up through the sand to the top of the tank. This action separates the debris from the sand and carries it to the top in the water.

Henry Winkler Terry Bradshaw New Show more. At the top the water and debris is collected and fed into the upper piping to be diverted out the WASTE Valve Port and Waste Line. The lower Valve Port, which normally returns waterr to the pool, is shut off.

PoolSupplyWorld carries an array of valves for your swimming pool filters from all the major brands you’ve come to know and trust. From Hayward to Sta-Rite and everything in between, we are certain to have exactly what you need.
